Hermetically Sealed Bi-Lobe® Nano D Connectors - MSA

Hermetically Sealed Bi-Lobe® Nano D Connectors

Name: Hermetically Sealed Bi-Lobe® Nano D Connectors
SKU: B-140-000580
Availability: InStock

Omnetics

Warning: Attempt to read property "ID" on null in /home/serverde/msa.server57.de/wp-includes/link-template.php on line 394

Warning: Attempt to read property "ID" on null in /home/serverde/msa.server57.de/wp-includes/link-template.php on line 409

SKU: B-140-000580 Category: Uncategorized

Description
More Information

Description

MIL-DTL-32139 compatible Hermetic Connectors are ideal for high pressure applications that require low leakage rates such as Optics, Cryogenics, Petroleum, Space and UAV systems. Available in weld-able or solder-able bulkhead mounts with 9-65 positions.

Each contact is sealed with a proprietary dispersion strengthened,devitrifying olycrystalline ceramic compound that offers performance above and beyond conventional glass seals. Due to its non-amorphous crystalline structure this ceramic is five times more resistant to fracturing than glass. These nano-miniature connectors are capable of achieving helium leak rates of less than 1x10-9 cc/sec Helium at 1 atmosphere of differential pressure.

Please contact us for further information

www.omnetics.com
